20mm Standard Servo CLS2511S, HV, ALU, MG
CLS2511S
The CLS2511S is a high-performance servo in the 20mm class, designed for demanding applications. Featuring steel gears, a full CNC aluminum housing, and a coreless motor, it offers excellent reliability and power.
With support for voltages up to 8.4V, it delivers outstanding performance for high-voltage setups. Dual ball bearings ensure smooth operation, and its waterproof design makes it suitable for various environments.
Dead band: 2μs default
Working frequence: 1520μs / 330hz
Operating Voltage: DC6.0~8.4 V
Operating Speed (6.0V): 0.13sec/60 º
Operating Speed (7.4V): 0.11sec/60 º
Operating Speed (8.4V): 0.10sec/60 º
Stall Torque (6.0V): 22.3kg.cm
Stall Torque (7.4V): 25kg.cm
Stall Torque (8.4V): 28.5 kg.cm
Dimentions: 40x20x40.9mm
Weight: 80g
Bearings: 2BB
Connector Wire Length: 300mm
Spline: 25T (Futaba)
Water Resistant
| Stall Torque (8.4V): 28.5kg.cm |
| Stall Torque (7.4V): 25kg.cm |
| Stall Torque (6V): 22.3kg.cm |
| Blokiermoment(5V): 20.2kg.cm |
| Speed (8.4V): 0.10sec/60° |
| Speed (7.4V): 0.11sec/60° |
| Speed (6V): 0.13sec/60° |
| Geschwindigkeit(5V): 0.15s/60° |
| Family: 20mm Alu |
| Weight: 80g |
| Gear: Steel |
| Body: Aluminum |
| Ball Bearings: 2BB |
| Motor: Coreless |
| Softstart: No |
| Programmable: Yes |
| Axis: 5.90/25T/Futaba |
| Width: 20mm |
| Length: 40mm |
| Height: 39mm |
Internal Reference:
CLS2511S
