8mm Wing Servo CLS0512W, HV, ALU, MG
C308
High-quality and powerful 6mm top-class servo with an excellent performance
The C308 Wing Servo offers an unmatched performance in an incredibly compact 6mm design. With high-precision steel gears, a coreless motor, and a full CNC aluminum case, this servo delivers exceptional reliability and power. At only 8g, it achieves 3kg.cm of torque and 0.08s/60° speed, operating efficiently between 3.5V and 7.4V. Its ultra-thin profile of just 6mm makes it perfect for tight spaces, while the dual ball bearing system ensures smooth and precise movement.
Note: Due to its compact motor design (7mm diameter, protruding 0.5mm), mechanical blocking above 3kg.cm torque can damage the servo. Operation at 8.4V is possible but may generate additional heat.
Working frequence: 1520μs / 330hz
Operating Voltage: DC3.5~8.4 V
Operating Speed(3.5V):0.17sec/60degrees
Operating Speed(5.0V):0.13sec/60degrees
Operating Speed(6.0V):0.10sec/60degrees
Operating Speed(7.4V):0.8sec/60degrees
Operating Speed(8.4V):0.7sec/60degrees
Stall torque(8.4V):3.00kg.cm(58.33oz/in)
Rated working torque(3.5V):0.45kg.cm(13.89oz/in)
Rated working torque(5.0V):0.65kg.cm(22.22oz/in)
Rated working torque(6.0V):0.77kg.cm(27.78oz/in)
Rated working torque(7.4V):0.96kg.cm(37.50oz/in)
Dimensions:22.5*6*21mm
Weight:8g
Connector Wire Length:JR180mm(7.02in)
Bearings: 2BB
Spline: Mini 25T
| Stall Torque (8.4V): 3.00kg.cm |
| Stall Torque (7.4V): 2.5kg.cm |
| Stall Torque (6V): 1.9kg.cm |
| Blockiermoment(5.0): 1.60kg.cm |
| Blockiermoment(3.5V): 1.20kg.cm |
| Speed (8.4V): 0.07s/60° |
| Speed (7.4V): 0.08/60° |
| Speed (6V): 0.10/60° |
| Geschwindigkeit(5V): 0.13s/60° |
| Geschwindigkeit(3.5V): 0.17s/60° |
| Family: 6mm Wing |
| Weight: 8g |
| Gear: Metall |
| Body: Aluminum |
| Ball Bearings: 2BB |
| Motor: Coreless |
| Softstart: No |
| Programmable: No |
| Axis: 4.90/25T |
| Width: 6mm |
| Length: 22.5mm |
| Height: 21mm |
Internal Reference:
C308
