9mm PRO Navigation Light, 2.5Wx2, SHORT

https://www.unilight.at/web/image/product.template/1400/image_1920?unique=38a6efe

PRO9X-025x2

The compact version of 9mm range navigation lights

​Angled design for optimal light distribution in all sectors. Short form factor allows it to fit even in areas with limited installation depth, such as a navigation light at the air inlet vents.

​

Electricity: 2.5Wx2 reference power in 2x technic,
Voltage: 8(12)V,0.2A
Beam angle: 0 to 180°
Light intensity: ~50 Lumen RED
Light intensity: ~120 Lumen GREEN
Light intensity: ~210 Lumen WHITE
Dimension: 9.5x32x18mm
Weight: 4g (without cable)

Delivery Content:

With 1m silicone connection cable, fully assembled with a high-quality polycarbonate cap that should be glued to the model.

19.92 € 19.92 EUR 19.92 €

19.92 €

Not Available For Sale

  • Operating Voltage
  • Cable Length
  • Colour
  • Design
  • Function
  • Dimensions

This combination does not exist.

Contact Us
Operating Voltage: 2S/8V or 3S/12V with additional resistor
Cable Length: 0.5m PTFE 0,14mm²
Design: profile-shaped
Function: Navigation/Position Light
Dimensions: 9mm

Short URL

Assembly Instruction:

Use additional resistor for 3S operation.

Warning Notice:

Please note that high-performance LEDs can become very warm, up to 70°C is completely normal. These heat sink mounted lights are suitable for continuous operation when air convection is possible. After installation, check the operating temperatures. We cannot guarantee against overheating. Attention: The LED lights are extremely bright! Never look directly into an LED!
