9mm DUAL Navigation Light + Strobe, 6Wx2 - SHORT
DUAL9X-060x2
Very compact and powerful navigation light with integrated strobe!
The angled design ensures optimal forward emission for the position light and side emission for the strobe. Provides excellent visibility with minimal glare, just like the prototypes. The extremely compact design makes it easy to integrate in smaller models and tight spaces but also in bigger projects.
Order includes a highly transparent and extremely break-proof cover cap made of injection-molded polycarbonate. The cap must be glued to the light module on the model.
Performance: 2Wx2 RED/GREEN and 3Wx2 WHITE reference power,
Voltage: 8(12)V; 0.2A RED/GREEN, 0.3A WHITE
Beam angle: 0 to 120° RED/GREEN, 60° to 180° WHITE
Light intensity: ~50 Lumen RED
Light intensity: ~100 Lumen GREEN
Light intensity: ~300 Lumen WHITE
Dimension: 9.5x32x18mm
Weight: 4g (without cable)
Equipped with 1m silicone connection cable, fully assembled with high-quality polycarbonate cap
| Operating Voltage: 2S/8V or 3S/12V with additional resistor |
| Cable Length: 1m Silicone 0.25mm² |
| Design: profile-shaped |
| Function: Dual Navigation/Strobe |
| Dimensions: 9mm |
Use additional resistor for 3S operation.
The cap must be glued to the light module on the model.
Please note that high-performance LEDs can become very warm, up to 70°C is completely normal. These heat sink mounted lights are suitable for continuous operation when air convection is possible. After installation, check the operating temperatures. We cannot guarantee against overheating. Attention: The LED lights are extremely bright! Never look directly into an LED!
